Anti-Covert Photography Detection Equipment
An all-in-one detection kit integrating WiFi/Bluetooth, mobile signal, pinhole camera, infrared imaging, and endoscope modules. With smart analysis and alerts, it quickly identifies hidden surveillance threats.
Features
WiFi Signal Detection
Instantly scans suspicious hotspots and identifies hidden surveillance networks.
Mobile Signal Detection
Monitors abnormal mobile traffic and alerts potential threats in real time.
Infrared Thermal Imaging
Scans for temperature anomalies to pinpoint hidden devices or risks.
Bluetooth Signal Detection
Analyzes Bluetooth devices in the area and quickly locates suspicious targets.
Pinhole Camera Detection
Uses infrared laser technology to detect and locate hidden cameras with precision.
Endoscope Detection
Explores hard-to-reach areas to uncover concealed surveillance devices.
Application Scenario
Hotel Rooms
Temporary Offices
Sensitive Site Inspections
Vehicle inspection
Technical Parameters
| Module | Parameter | Specification |
|---|---|---|
| WiFi Signal Detection Unit | WiFi Hotspot Parsing | MAC address, SSID (including hidden WiFi hotspots), channel number, signal strength, encryption method, topology relationship |
| Supported WiFi Protocols | 802.11 a/b/g/n/ac/ax | |
| Terminal Information Parsing | MAC address, SSID, channel number, signal strength | |
| Detection Sensitivity | ≤ -80 dBm | |
| Positioning | Supports proximity-assisted positioning | |
| Bluetooth Signal Detection Unit | Supported Bluetooth Types | Bluetooth recording devices, mobile phones, watches, earphones, etc. |
| Supported Protocols | Bluetooth 1.0 ~ 5.2 | |
| Detection Sensitivity | ≤ -90 dBm | |
| Positioning Accuracy | ≤ 1 m | |
| Positioning | Supports proximity-assisted positioning | |
| Mobile Signal Detection Unit | Detection Sensitivity | ≤ -90 dBm |
| Mobile Communication Analysis | Band number, Cell ID, bandwidth, signal strength, signal-to-noise ratio, operator | |
| Frequency Range | 70 ~ 6000 MHz | |
| Supported Mobile Standards | 2G / 3G / 4G / 5G | |
| Supported Operator Types | China Mobile, China Unicom, China Telecom, China Broadcasting | |
| Band Configuration | Supported | |
| Infrared Thermal Imaging Detection Unit | Infrared Resolution | 384 × 288 |
| NETD (Sensitivity) | ≤ 60 mK (@25°C, F#1.0) | |
| Temperature Range | -20° ~ 120°C | |
| Temperature Statistics | Supports max/min/center temperature display, up to 3-point measurement | |
| Evidence Collection | Photo, video | |
| Pinhole Camera Detection Unit | Detection Principle | Supports laser reflection |
| Detection Distance | 0.5 ~ 10 m | |
| Minimum Aperture of Target | ≥ Φ0.3 mm | |
| Laser Power | 5 nW ~ 100 mW (adjustable) | |
| Image Frame Rate | 15 fps | |
| Camera Recognition Ability | False alarm rate ≤ 5%, missed detection rate ≤ 5% | |
| Evidence Collection | Photo | |
| Endoscope Detection Unit | Physical Pixels | ≥ 5 MP |
| Maximum Resolution | ≥ 1920 × 1080 | |
| Evidence Collection | Photo, video | |
| Full-band Detection Unit | Spectrum Value Storage | Supported |
| Signal Comparison | Supported | |
| Scanning Range | Supports 70 MHz ~ 6 GHz full-band scanning | |
| Foreign Mobile Device Detection Alarm (Optional) | Supported Brands | Apple |
| Supported Devices | iPhone, Apple Watch, AirPods, iPad, Mac computer | |
| Parsing Content | Device model, device type, signal strength | |
| Real-time Positioning | Supports proximity-assisted positioning | |
| Integrated Analysis System | Automatic Report Generation | Includes WiFi/Bluetooth, mobile communication signals, infrared thermal imaging, hidden camera, and endoscope detection results |
| Report Export | Supports USB export | |
| Log Audit | Supported | |
| Host Parameters | Weight (with all modules) | ≤ 1.2 kg |
| Integration | All modules integrated except endoscope | |
| Storage | 256 GB | |
| Display Size | 8.8 inches | |
| Battery | 11550 mAh | |
| Working Time | ≥ 2 hours at full power |
